Specification
7 Domestic air conditioner
2.Specifications
NOMINAL DISTRIBUTION SYSTEM VOLTAGE
●
Phase / 1
Frequency Hz 50
Voltage V
220-240
NOMINAL CAPACITY and NOMINAL INPUT
Cooling heating
Capacity rated
kW 3.50 4.20
Btu/h
●
11940 14330
Power Consumption(Rated) kW 0.87 1.1
SEER/SCOP W/W 8.5/A+++ 4.6/A++
Annual energy consumption kWh 144 854
Moisture Removal m³/h
1.6*10﹣³
TECHNICAL SPECIFICATIONS-UNIT
Dimensions H*W*D
●
mm
800×275×553
Packaged
Dimensions
H*W*
D mm
908×405×625
KG
●
30
Gross weight / KG
32.9
Sound level
Sound pressure
dB 48
Sound power dB 61
ELECTRICAL SPECIFICATIONS
Cooling heating
Nominal running current A
3.9 5.0
Maximum running current A 6.7 7.2
Starting current A 1 1
TECHNICAL SPECIFICATIONS-PARTS
cooling heating
Compressor
Type Rotary Compressor
Model
GSD098RKTF6JV6B
Motor output
●
W 695
Oil type
ASC-68R or equivalent
Oil charge volume L
0.280±0.0±2
Fan
Type Axial fan
Motor output W
40
Air flow rate(high) m³/h
1900
Speed(high/low) rpm 850/300
Heat Type ML fin-φ7HI-HX tube
Net Weight
