Specifications
9
Domestic air conditioner
TECHNICAL SPECIFICATIONS-PARTS
cooling heating
Fan
Type Cross flow fan
Motor output W 25 25
Air flow rate(high) m³/h 500 450
Speed(super/high/low) rpm 1150/1000/850 1050/ 900/750
Heat exchanger
Type ML fin-φ 5HI-HX tube
Segment *stage*fitch 3*15*1.3
Air direction control Horizontal,Downward
Air filter
Removable/Washable/Mildew Proof
Temperature control
Microcomputer Control
Remote controller model 0010401715DG
Note: the data are based on the conditions shown in the table below
cooling heating Piping length
Indoor: 27 DB/19 WB℃ ℃
Outdoor: 35 DB/24 WB℃ ℃
Indoor:20 DB℃
Outdoor: 7 DB/6 WB℃ ℃
5m
4.Sensors list
Conversation formulae
Kcal/h= KW×860
Btu/h= KW×3414
cfm=m³/min×35.3
type Description Qty
1rofdesustIm and pipe sensor oo erutarepmet rotaropave dna mR oorgnitceted
