Specification
7
Domestic air conditioner
2.Specifications
NOMINAL DISTRIBUTION SYSTEM VOLTAGE
●
Phase / 1
Frequency Hz
●
50
Voltage V 230
NOMINAL CAPACITY and NOMINAL INPUT
●
Cooling heating
Capacity rated
KW 7.0 8.1
Btu/h 23880 27640
Power Consumption(Rated) KW 2.16 2.18
SEER/SCOP W/W 7.1/A++ 4.0/A+
Annual energy consumption KWh 350 1963
Moisture Removal m³/h
2.8*10
﹣³
TECHNICAL SPECIFICATIONS-UNIT
Dimensions H*W*D mm 890×353×697
Packaged
Dimensions
H*W*D mm 1046×460×780
Weight / KG 47.3
Gross weight / KG 52.3
Sound level
Sound peessure dB 52
Sound power dB 65
ELECTRICAL SPECIFICATIONS
Cooling heating
Nominal running current
●
A 9.6 9.7
Maximum running current
●
A 13 13
TECHNICAL SPECIFICATIONS-PARTS
cooling heating
Compressor
Type Rotary Compressor
Model GTD186UKQA8JT6
Motor output W 992
Oil type A C S - 6 8 R o r e q u i v a l e n t
Oil charge volume L 0.5
Fan
Type Axial fan
Motor output W 50
Air flow rate(high) m³/h 2900
Speed(high/low) rpm 800/300
Heat
exchanger
Type ML fin-φ7HI-HX tube
Row*stage*fitch 2*15*1.4
