- 10 -
Service Manual
Model No.:
Keypad and remote connector (J 2)
Speaker connector (J 17)
Pin number Signal name Description
1RSPK+ RSPK+
2 RSPK- RSPK-
3LSPK- LSPK-
4LSPK+ LSPK+
Pin number Signal name Description
1
LED_R
LAMP RED
2
LED_G
LAMP GREEN
3
4
IR
REMOTE CONTROL
5
GND
GND
6
5V
POWER FOR REMOTE
7
KEY1
KEY0
10
GND
8
9
NC
STANDBY
