Introduction
Introduction
1. Front View
1). (IR) Infrared Receiver: Receives IR signals from the remote control.
(Power on/Standby)LED Indicator: Press POWER to turn on and off.
Indicator on(Red) Standby mode
Indicator off Power on mode
2).
The functions of the buttons:
INPUT: Press to show the input source list. Use the up and
down arrow keys to select a source, and then press
the VOL + key.
MENU: Press to display the OSD (on screen display) menu,
press again to exit the menu.
VOL+/-: Press to adjust the volume. In the OSD menu, use
the VOL+/- buttons to move right/left.
The effective receiving range for the signal is up to 26 feet from the front of the remote
control window, and 30
0
to the right side and 20
0
above or below the remote control
window.
Led Indicator
Remote Control window
(Keep clear)
POWER/STANDBY: Turn on/off (standby) the
TV set.
CH / : Press to scan through channels. In the OSD
menu, use the CH /\ / \/ buttons to move up/down.
6
