8 OFF ON ON ON
9 ON OFF OFF OFF
10 ON OFF OFF ON
11 ON OFF ON OFF
12 ON OFF ON ON
13 ON ON OFF OFF
14 ON ON OFF ON
15 ON ON ON OFF
16 ON ON ON ON
If you use central control type, SW1, SW2 will be used simultaneously.
Wiring request in central control type: port A-B is connected with indoor port CN16（A-B）
through 2-core shield wire. Requirements:
1. Port A connects with port CN16（A）of all indoor units.
2. Port B connects with port CN16（B）of all indoor units.
Address on
central
controller
Indoor unit
address
SW2-3 SW2-2 SW2-1 SW1-4 SW1-3 SW1-2 SW1-1
1 1 ON OFF OFF OFF OFF OFF OFF
2 2 ON OFF OFF OFF OFF OFF ON
3 3 ON OFF OFF OFF OFF ON OFF
4 4 ON OFF OFF OFF OFF ON ON
5 5 ON OFF OFF OFF ON OFF OFF
6 6 ON OFF OFF OFF ON OFF ON
7 7 ON OFF OFF OFF ON ON OFF
8 8 ON OFF OFF OFF ON ON ON
9 9 ON OFF OFF ON OFF OFF OFF
10 10 ON OFF OFF ON OFF OFF ON
11 11 ON OFF OFF ON OFF ON OFF
12 12 ON OFF OFF ON OFF ON ON
13 13 ON OFF OFF ON ON OFF OFF
14 14 ON OFF OFF ON ON OFF ON
15 15 ON OFF OFF ON ON ON OFF
16 16 ON OFF OFF ON ON ON ON
17 -------- ON OFF ON OFF OFF OFF OFF
18 -------- ON OFF ON OFF OFF OFF ON
19 -------- ON OFF ON OFF OFF ON OFF
20 -------- ON OFF ON OFF OFF ON ON
21 -------- ON OFF ON OFF ON OFF OFF
22 -------- ON OFF ON OFF ON OFF ON
23 -------- ON OFF ON OFF ON ON OFF
24 -------- ON OFF ON OFF ON ON ON
25 -------- ON OFF ON ON OFF OFF OFF
