Haier AD482MPERA Design, Installation & Maintenance Instruction

11
2. Specication
Equivalent HP 8 10 12
Model AV08IMWEWA AV10IMWEWA AV12IMWEWA
Combination model / / /
Capacity
Cooling capacity kW 22.4 28 33.5
Heating capacity kW 25 31.5 37.5
Electrical
Parameters
Power supply Ph/V/Hz 3Ph/380V/50-60Hz
Cooling
Rated power input kW 4.50 6.00 7.70
Max. power input kW 13.00 15.00 17.00
Rated current A 5.95 7.93 10.17
Max.current A 17.18 19.82 22.46
Heating
Rated power input kW 4.15 5.80 7.80
Max. power input kW 13.00 15.00 17.00
Rated current A 5.48 7.66 10.31
Max.current A 17.18 19.82 22.46
EER 4.98 4.67 4.35
COP 6.02 5.43 4.81
Performance
Water ow (H) m3/h 4.8 6 7.2
Sound pressure level (H) dB(A) 50 51 53
Sound power level (H) dB(A) 61 62 64
Installation
External dimensions(W/D/H) mm 775×545x995 775×545x995 775×545x995
Shipping dimensions(W/D/H) mm 875×655×1182 875×655×1182 875×655×1182
Net weight kg 150 150 150
Shipping weight kg 170 170 170
Compressor type DC INV. SCROLL DC INV. SCROLL DC INV. SCROLL
Compressor brand
MITSUBISH
ELECTRIC
MITSUBISH
ELECTRIC
MITSUBISH
ELECTRIC
Compressor quantity 1 INV 1 INV 1 INV
Refrigerant type R410A R410A R410A
Refrigerant charge kg 6 6 6
Refrigerant liquid pipe mm Ф9.52 Ф9.52 Ф12.7
Refrigerant gas pipe mm Ф19.05 Ф22.2 Ф25.4
Oil equalization pipe mm Ф9.52 Ф9.52 Ф9.52
Total pipe length m 300 300 300
Max. pipe length(Equivalent/Actual) m 150/120 150/120 150/120
Max drop between I.U.&O.U m 50/40 50/40 50/40
Heat Exchanger
Type Double coil Double coil Double coil
Material Cooper Cooper Cooper
circulating water ow m3/h 4.8 6 7.2
Diameter mm 235 235 235
Height mm 635 635 635
Water side
Inlet water connection pipe mm DN32 DN32 DN32
Outlet water connection pipe mm DN32 DN32 DN32
Drain outlet mm 6.35 6.35 6.35
pressure drop( inlet and outlet) Kpa 35 40 45
Connection type inner grooved inner grooved inner grooved
Max. system water pressure Mpa 1.96 1.96 1.96
Inlet water temperature range(Cooling &
Heating)
℃
7~45 7~45 7~45
Connection Ratio
Connectable indoor unit ratio % 50-130 50-130 50-130
Maximum number of indoor units unit 13 16 19

Haier AD482MPERA Specifications

General

Brand	Haier
Model	AD482MPERA
Category	Air Conditioner
Language	English
