6) EE data inquiry
SW9 SW10 SW11 Function Digital tube LD1-4 display
12
0 0 000H address’s EE data (E2 version)
EE’s previous 256 byte data display (system parameter info)
Address calculating method: addr. = SW10 × 16
＋
SW11
Data display: hexadecimal; H represents hexadecimal number
0 1 001H address’s EE data
… … …
0 15 00FH address’s EE data
1 0 010H address’s EE data
… … …
1 15 01FH address’s EE data
… … …
15 15 FFH address’s EE data
13
0 0 100H address’s EE data
EE’s later 256 byte data display (malfunction info)
Address calculating method: addr. = SW10 × 16 + SW11
Data display: hexadecimal; H represents hexadecimal number
Dial plate shows 13,0,0. Press SW2 (UP) for 2 secs continuously to
eliminate EE’s later 256 byte data.
0 1 101H address’s EE data
…… …… ……
1 15 11FH address’s EE data
…… …… ……
15 15 1FFH address’s EE data
7) PCB Special No. Description
SW9 SW10 SW11 Description
15 0 0
Special No.
3 pipes model: 084A
MX6-S and Water Cooled VRF: 084A
8) Reserved part
SW9 SW10 SW11 Function
4 0-15 0-15
5 0-15 0-15
14 0-15 0-15
1 2-15 2
2-3 0-15 2
6 0-15 0-1,3-15
7 0-15 0-3,15
8 0-15 0-3,15
9 0-15 0-3,15
10 0-15 0-3,15
11 0 5-15
11 1-10 4-15
11 11-15 0-15
15 0 1,3-15
15 1-15 0-1,3-15
