Haier AFD631GR

7
SERVICE MANUAL
Model:AFD631GW/GB/GR
7
Issue 201003
Rev. Ref11003S006V0
Freezer
-16 ~-25°C -16 ~-25°C -16 ~-25°C
Features:
Energy consumption per l 100 net / year
kWh 0.282 0.282 0.282
Energy consumption per l 100 net / 24h
kWh 0.87 0.87 0.87
C
oolin
g
s
y
stem: K=Compressor / A=Absorption
K K K
Max noise level
dB(A) 42 42 42
4
Aesthetics
C
olors: W=white G=silver gray
R=red B=Obsidian SS=stainless steel
B/W B/B B/R
Fascia panel / Handle (w / c)
B/ss B/ss B/ss
F= flat / R= rounded / S= streamline
R R R
Inside colour
w w w
Compartments number
n° 3 3 3
Bottle compartment
n° 4 4 4
Hinged (r =right l =left) / reversible
r / X r / X r / X
Shelves:
Number Fridge / Freezer
3 / - 3 / - 3 / -
Type (gr=grill / g=glass / p=plastic)
g / - g / - g / -
Color w-white / b=blue / t=transparent.
t t t
Adjustable (Y=yes / N=not)
yes yes yes
Foldable Shelf
yes yes yes
Bottle Rack
yes yes yes
Drawers:
Plastic drawers (fully freezing comp.)
n°. 2 2 2
Half freezing comp
n°. 2 2 2
Colour of drawer (w=white/t=transp./g=green)
w/t w/t w/t
Crisper:
Chiller / Meat (salad crisper) transparent / white
Chiller (t) Chiller (t) Chiller (t)
Vegetable crisper(s) transparent / white
t t t
5
Equipment & accessories
Control panel
Interior / exterior
Interior Interior Interior
Thermometer interior / exterior
Interior Interior Interior
Display type
LCD LCD LCD
Control lamps green / yellow /white
w w w
Over temperature alarm LED / acoustic acoustic acoustic acoustic
Adjustable thermostat
yes yes yes
Fast freeze switch /-function
yes yes yes
Deodorizing
yes yes yes
Interior light
W yes yes yes
LED light
n° Full Full Full
Freeze pack(s)
n° 2 2 2
