Haier AFD631GR

8
SERVICE MANUAL
Model:AFD631GW/GB/GR
8
Issue 201003
Rev. Ref11003S006V0
ice maker Manual/ Automatic
M M M
Ice cube tray(s)
n° 1 1 1
Butter holder
yes yes yes
Egg trays
2 2 2
Adjustable feet front / rear
n° 2 / - 2 / - 2 / -
Length of cable/incl. plug
cm 200 200 200
Condenser Back wall / Integrated
B B B
6
Product dimensions
Unit dimensions ( H / W / D)
cm 188/60/67 188/60/67 188/60/67
Depth Without handle
cm 67 67 67
Depth with open door
cm 1188 1188 1188
Door open angle
n° <135 <135 <135
Net weight
kg 88 88 88
7
Packing dimensions & load ability
Packing dimensions (H / W / D)
cm 194.7/66.4/73 194.7/66.4/73 194.7/66.4/73
Gross weight
kg 96 96 96
40 ' Container load
pcs 54 54 54
40 ' HC Container load
pcs 72 72 72
8
Recycling symbols
Packing materials / Recycling symbols (RS)
RS RS RS RS
Carton weight in gr
6270 6270 6270
Polystyrene weight in gr
06 2570 2570 2570
Polyethylene foil weight in gr
04 210 210 210
9
Service
Users instruction (languages)
D / F / I / GB / E / P / NL
2-2 Main Functions and Features
◆ Energy saving and convenience (only in some models).
◆ Half-shelf structure.
◆ Innovative long-efficiency lighting system.
◆ Foldaway wine holder.
◆ Large crisper with humidity adjustment.
◆ Holiday function.
◆ Power ON/OFF function is set on the display panel (only in some models).
◆ Fridge storage compartment can be set on/off separately.
◆ Intelligent alarm function: automatic alarm at over temperature, malfunction, door open.
◆ Touch keys (only in some models).
◆ Deodorizer (only in some models).
◆ Zero degree fresh keeping.
