Haier AV08IMVEVA - Transportation

5
• The unit is better not be installed
at the below places, or it will cause
damage.
• The place where there is corrosive
gas (spa area etc).
• The place blowing salty air (seaside
etc).
• Exsits the strong coal smoke.
• The place with high humidity.
• The place where there is device
emitting Hertzian waves.
• The place where voltage changes
greatly.
• The place where the water can ow
uently.
• The place where no other heat
source will affect the unit.
• Pay attention to the snow against
clogging the outdoor.
• In installation, install the anti-
vibration rubber between the unit
and the bracket.
The unit should be installed at the
place where the cold/hot air or
noise will not interfere the neighbours.
Transportation
• In transportation, please don't dismantle the packaging, and move the unit to the installation location as closely as
possible.
• Don't hang the unit only at two points. When hanging the unit, don't sit on the unit. The unit should be upright. When
removing the unit with the forklift, put the fork into the special hole at bottom of the unit. When being hanged, the rope
should be 4 pieces of steel cable with over 8mm diameter. Put the cushion at the contact section between steel cable
and the unit against the distortion or damage.
steel cable
cushion
Forklift hole
distance
480mm
Hoisting hole diameter Ø40mm, distance730mm
AV08~16IMVEVA
Forklift hole
distance
480mm
Hoisting hole diameter Ø40mm, distance1042mm
AV18~26IMVEVA
Installation instruction
