SERVICE MANUAL
Model:
16
Issue
Rev.
Chapter 3 Installation, adjustments and maintenance
3-1. Door (Refrigerator door, Freezer door)
3-1-1.Removing and replacing the right door of refrigerator compartment
3-2. Water pipe
3-3. Water supplied time
A) Unscrew the four screws which secure the front panel
located at the top;
B) Push the front panel upward to withdraw the front panel;
C) Pull the hinge cover upward;
D) Disconnect the two connected terminals of electric cable;
E) Push the small cover on the right side of the front panel by
one hand to withdraw the small cover;
To Next Page
