Why is my Haier CA0035EANE making abnormal noise?
If your Haier Air Conditioner is making an abnormal noise, it could be due to loose metal plate bolts. Try retightening them. Alternatively, the noise might be caused by liquid refrigerant entering the compressor. In this case, adjust the charge of refrigerant or the throttling device.
Why is the suction pressure low in my Haier CA0035EANE Air Conditioner?
If your Haier Air Conditioner has low suction pressure, it could be due to several reasons. You might have insufficient refrigerant, in which case you should adjust the refrigerant charge. Another cause could be an undesirable low-pressure switch, which would need to be replaced. Insufficient water flow or low water inlet temperature at the water side could also cause this, requiring you to check the water flow and temperature, respectively. A scaled or obstructed water-side heat exchanger, insufficient air capacity (check the fan), a short circuit in the air circuit (find the cause and troubleshoot), or incomplete defrosting (replace the 4-way valve or defrosting sensor) are other potential causes.
How to fix fault in communication of wired controller in Haier Air Conditioner?
If there's a fault in the communication of the wired controller for your Haier Air Conditioner, the unit numbering might be incorrect; check and correct it. Also, the connection of communication wires could be incorrect; check their order. A damaged PCB could also be the problem, requiring replacement. Finally, the wired controller itself might be faulty and need replacement.
What causes too low exhaust pressure in Haier CA0035EANE?
If the exhaust pressure of your Haier Air Conditioner is too low, it could be due to a lack of refrigerant, so adjust the charge. It might also be caused by low suction pressure. Low ambient temperature of the air-side heat exchanger or too low water temperature at the water side could also be the cause; check the ambient and water temperatures respectively.
What causes high suction pressure in Haier CA0035EANE?
High suction pressure in your Haier Air Conditioner can be caused by a few things. You might have too high a charge of refrigerant; in that case, adjust the charge. Another possibility is a high water inlet temperature at the water side; check the water temperature. It could also be due to a high ambient temperature of the air-side heat exchanger; check the ambient temperature.
What to do if there is a fault in flow switch of Haier CA0035EANE Air Conditioner?
If there is a fault in the flow switch of your Haier Air Conditioner, there might be air in the water system, which can be resolved by discharging air via the exhaust valve. Alternatively, the water-side heat exchanger might have scaling or foreign matter inside, requiring you to clean the incrustation scale. The switch itself could be poor and need replacement. Unevenly distributed flow in water pipelines can also cause this issue; adjust the flow via the shut-off valve. An out-of-service water pump might be the cause, requiring machine installation. Insufficient types of water pumps could be the reason, so check and try to fix it.
What causes overtemperature of exhaust temperature sensor in Haier CA0035EANE?
If the exhaust temperature sensor of your Haier Air Conditioner is over temperature, it could be due to poor ventilation around the unit. Try cleaning up any obstacles or adding air ducts. It could also be caused by too low an ambient temperature, in which case you should shut down the unit. A dirty or clogged filter at the fluorine side could also be the cause, so replace the filter. Finally, incomplete or no frosting (for heating) could be the issue; change the frosting parameters.
What to do if Haier CA0035EANE has open or short circuit of temperature sensor?
If your Haier Air Conditioner's temperature sensor has an open or short circuit, it could be due to a damaged sensor, in which case you should replace it. Alternatively, it could be due to a poor connection of the sensor; try reconnecting it.
What causes open circuit in low-pressure sensor of Haier Air Conditioner?
If there is an open circuit in the low-pressure sensor of your Haier Air Conditioner, it might be because the sensor is damaged, and you'll need to replace it. It could also be due to a poor connection of the sensor; try reconnecting it.
What to do if Haier CA0035EANE Air Conditioner exhaust pressure is too high?
If your Haier Air Conditioner's exhaust pressure is too high, several factors could be the cause. It could be due to air or non-condensable gas in the system, which requires discharging and emptying the gas. A high suction pressure could also be the reason. Other potential causes include a faulty high-pressure switch (which would need replacement), a dirty or clogged condenser fin (requiring cleaning of the air-side heat exchanger), insufficient air capacity or a faulty condenser fan (requiring a fan check), a high refrigerant charge (requiring adjustment), high ambient temperature (requiring inspection), insufficient water flow (requiring a water flow check), scaling or foreign matter in the water-side heat exchanger (requiring cleaning), or a high outlet temperature of the water-side hea...
General description of the modular air-cooled chiller unit's features and benefits.
Details on the unit's advanced technology for improved efficiency and reduced noise.
Information about the electronic controller for centralized and independent unit operation.
Focuses on the unit's ease of installation, compact design, and flexible placement options.
Highlights safety features like pressure protection, anti-freezing, and over-temperature protection.
Explains accessibility of parts for maintenance and fault code display for troubleshooting.
Explanation of warning and caution symbols used throughout the manual.
Crucial safety instructions for installation, maintenance, and operation to prevent injury or damage.
Diagrams showing the external dimensions of the chiller unit.
Guidelines for selecting and preparing the base for unit installation.
Detailed base diagram and mounting specifications for the CA0035EANE model.
Detailed base diagram and mounting specifications for the CA0070EANE model.
Detailed base diagram and mounting specifications for the CA0100EANE model.
Detailed base diagram and mounting specifications for the CA0130EANE model.
Steps and checks required before starting the installation process.
Instructions for safely handling and disassembling the unit before installation.
Criteria and considerations for choosing the optimal installation location for the unit.
Diagrams illustrating required clearance for installing a single chiller unit.
Diagrams showing recommended spacing for multiple chiller units.
Diagram showing spatial arrangement and spacing for multiple chiller units.
Detailed instructions and requirements for connecting the water pipes to the unit.
Specifications and criteria for water quality to ensure proper unit operation.
Visual representation of the water system components and connections.
Essential guidelines for connecting and preparing the water pipelines before operation.
Procedures and safety measures for connecting the unit's electrical power supply.
Includes pre-startup checks, pre-operation inspection, and monitoring of operation status.
Table showing nozzle dimensions based on the number of combined modules.
Guidance on calculating the required water system capacity based on unit models.
Recommendations for selecting auxiliary electric heaters based on operational needs.
Wiring diagrams for connecting the unit's power cords and breakers.
Table listing electrical specifications like rated current, maximum current, and cable size.
Instructions for setting module addresses using the eight-digit code switch.
Specifications and guidelines for selecting and routing communication wires.
Diagram illustrating the connection of communication wires between units and the handset.
Procedures for inspecting and cleaning the condenser for optimal heat exchange.
Guidance on cleaning the water-side heat exchanger and checking temperatures.
Information on refrigerant and lube oil levels and when make-up is required.
List of fault codes, their descriptions, and recovery methods for system errors.
Troubleshooting common issues like high/low pressure, overtemperature, and abnormal noise.
Further troubleshooting for faults like flow switch errors, controller issues, and compressor faults.
Table detailing cooling/heating capacity, power input, and refrigerant specifications.
Details on operating ranges for cooling and heating, and service condition requirements.
Correction factors for CA0035EANE model under various ambient and water outlet temperatures.
Correction factors for multiple models based on ambient and water outlet temperatures.
Heating correction factors for various models and temperature conditions.
Guidance on contacting dealers for support with moving and re-installing the unit.
Information on restricted substances and the importance of recycling refrigerant before scrapping.
Details on free repair/replacement within 18 months and lifelong maintenance services.
Provides hotline, address, and email for Haier after-sales service.
Confirms compliance with Low Voltage Directive and Electromagnetic Compatibility.
States fulfillment of requirements regarding restriction of hazardous substances.
Provides information on the proper disposal and recycling of electrical and electronic products.
General| Cooling power | 3.5 kW |
|---|---|
| Timer | Yes |
| Colour | White |
| Cooling Capacity | 3.5 kW |
| Power Supply | 220-240V, 50Hz |
| Noise Level (Outdoor) | 50 dB |
| Cooling power in BTU | 12000 BTU |
