Functions and control
17
Domestic air conditioner
7.Outdoor Functions and Control
7.1 Main functions and control specification
7.1.1 The operation frequency of outdoor unit and its control
7.1.1.1 The operation frequency control of compressor
The operation frequency scope of compressor˖
Mode Minimun operation frequency Maximun operation frequency
Heating 25Hz 105Hz
Refrigeration 25Hz 69Hz
7.1.1.2 The starting of compressor
When the compressor is started for the first time, it must be kept under the conditions of 38Hzˈ
58Hz,88Hz for one minute (the overheating protection of the outdoor unit air-blowing temperature,
immediately decrease the frequency when the compressor is overflowing and releasing the pressure)ˈ
then it can be operated towards the target frequency. When the machine runs normally, there’s no
such process. After starting the compressor for operation, the compressor should run according to the
calculated frequency, and every determined frequency for protection should be prior to the calculated
frequency.
7.1.1.3 The speeds of increasing or decreasing the frequency of the compressor
The speed of increasing or decreasing the frequency rapidly 1 -----------1HZ/second
The speed of increasing or decreasing the frequency slowly 2 -----------1HZ/10seconds
7.1.1.4 The calculation of the compressor’s frequency
1˅The minimum/maximum frequency limitation
AˊWhile refrigerating: F-MAX-r is the maximum operation frequency of the compressor; F-MIN-r is the
minimum operation frequency of the compressor.
BˊWhile heating: F-MAX-d is the maximum operation frequency of the compressor; F-MIN-d is the
minimum operation frequency of the compressor.
2˅The frequency limitation which is affected by the environment temperature.
(Wh_c= environment temperature)
Heating mode:
Serial No. Temperature scope Frequency limitation
1 Wh_c<-12 Max_hz8 105HZ
2 Wh_c<-8 Max_hz7 99HZ
3 Wh_c<-2 Max_hz4 90HZ
4 Wh_c<5 Max_hz5 80HZ
5 Wh_c<10 Max_hz1 80HZ
6 Wh_c<17 Max_hz2 75HZ
7 Wh_c<20 Max_hz6 54HZ
8
Wh_c>˙20
Max_hz3 35HZ
Remarks: The above are the maximum frequency limitations of the complete appliance which are
