EN
10 - Installation
23
11. Remove screw and axe cover. Remove hinge axe
and x it into the hole next to it.
12. Take the thicker axe cover from the accessory
bag. Fix it with screw from last step.
13. Fix the hinge to the opposite position of the cabinet
with 4 screws.
14. On opposit side of the door, pull out left side
connection cable and put it through the axe
cover from step 5, mount axe cover. Mount the
hole cover on the right side.
15. Mount the door.
16. Fix upper right upper hinge with 3 screws.
17. Connect the cable connectors:
18. Fix hinge hole cover and upper left hinge cover.
19. Finished.
13
11
12
14
15
18
17
19
16
