Figure 4.37 Eastron SDM630MCT
H3PH-1J5/6/8/10K-EU
Power cable
Note:
If the CT is installed in the wrong direction,
the Hybrid Inverter can't work normally.
CT direction
towards to grid
G
r
id s
i
d
e
K L
User Manual
4. Installation
27
