SERVICE MANUAL
Model: HB21FC45N*
6
Issue 2010-07-05
Rev. Ref1007S019V0
Chapter 2 Product Feature
2-1. SPECIFICATIONS
1 Model
HB21FC45NS HB21FC45NP HB21FC45NE
Product description (Refrigerator/Freezer) Refrigerator Refrigerator Refrigerator
Colour Grey smooth
cabinet/Stainless
steel door
White Smooth Black Smooth
Type of cooling system(NF=no frost/ S=static) NF NF NF
Climate class* T & ST T & ST T & ST
2. Key features
Total net capacity Cu.ft 20.6 20.6 20.6
Net capacity refrigerator compartment Cu.ft 14 14 14
Net capacity freezer compartment Cu.ft 6.6 6.6 6.6
Defrosting (M=manual A=automatic) A A A
Frost free system yes yes yes
Defrost water outlet yes yes yes
Air circulating ventilator yes yes yes
Kind of coolant R134a R134a R134a
3. Technical data
Voltage / frequency V/Hz 115V/ 60 115V/ 60 115V/ 60
Temperature range (from>to) °F -6>4 -6>4 -6>4
Refrigerator °F 36-42 36-42 36-42
Chiller / Meat Crisper °F ~>32F / - ~>32F / - ~>32F / -
Vegetable Crisper °F 34-40 34-40 34-40
Freezer °F -6-4 -6-4 -6-4
Cooling system: K=Compressor / A=Absorption K K K
4. Equipment & accessories
Control panel:
Interior / exterior Interior Interior Interior
Display type LED** LED** LED**
Control lamps green / yellow /white / / /
Over temperature alarm LED / acoustic Yes Yes Yes
Ice maker Manual/ Automatic A A A
Adjustable feet front / rear n° 2 /FRONT 2 /FRONT 2 /FRONT
Castors front / rear -/yes -/yes -/yes
Length of cable/incl. plug cm 352 352 352
5. Product dimensions
Unit dimensions ( H / W / D) mm 1772/908/700 1772/908/700 1772/908/700
Net weight kg 141 141 141
6. Packing dimensions & load ability
Packing dimensions (H / W / D) mm 1872/760/968 1872/760/968 1872/760/968
