DISASSEMBLY
13. Adjustable partition wall of freezer drawer
A movable partition wall is provided in the freezer drawer
to divide the drawer into two parts.
You may move the
partition wall right or left to meet your storage needs.
ıˇ
ı
Ǒ
ı ǒı
14. Replacing the Light Bulb(refrigerator)
Bulb specifications: 220V~, 25W
Socket: E14 (DO NOT use a bulb over 25W)
Unplug the appliance.
ķTo remove the light shield, press the stopper
at rear out of the square hole.
ĸ Pull the shield backward until the retainer is
separated from the square hole.
Turn the bulb anticlockwise and out. Replace a
bulb of the same specifications in the reverse
sequence of removal.
To replace the light shield: Engaged the retainer
into the square hole and then press the shield
rear forward until the stopper is locked in the
square hole.
Square
hole
Refrigerator
light socket
Retainer
Stopper
Light bulb

