DISASSEMBLY
10. Removing Crisper Cover
Take out the crisper and put it away. Lift up the cover end (1)
and remove it (2).
11. Cleaning door bin
Lift the bin up (1) and pull it towards you (2). Replace the bin in the
reverse sequence of
removal after cleaning.
12. Ice Cream Bin
An ice cream bin is provided to hold ice cream or similar
items to be stored at low
How to use the ice cream bin
1. To take out the ice cream bin, get the handle of it and pull
it towards you.
2. To clean the ice cream bin, follow these instructions:
ķ Pull the ice cream bin out to the stop position.
ĸLift the ice cream bin up (in the direction indicated by
Arrow 1) and remove it from the
refrigerator (in the
direction as indicated by Arrow 2).
Ĺ Replace the ice cream bin after cleaning in the reverse
sequence of removal.
temperatures.
(Fig 1)
Handle on
ice cream bin
(Fig 2)
