Haier HD70-01 ME Service Manual

- 16 -
Se r vice Manual
Model No: HD80-01/HD70-01
Issue
Re v.
6-2 Heater and bearing
1) Unscrew 15 screws on the rear
cover.
2) Take out the cover from the rear
panel.
1) Disassemble the top cover;
2) Disconnect the wire of heter.
Unscrew 4 screws on the cover of
air channel;
Unscrew 2 screws on the heater,
it can be disassembled.
heater wire

Haier HD70-01 ME Specifications

General

Brand	Haier
Model	HD70-01 ME
Category	Dryer
Language	English
