10
The system can generate the PWN signal to control the strength of TFT LCD Panel’s backlight through
this connector.
TFT LCD Panel(LVDS) Connector(CN4)
Keypad and remote connector(CN2)
Pin number Signal name Description
1-3 Power Power for panel
4-6 GND Ground
7 RXE0- LVDS EVEN 0 - Signal
8 RXE0+ LVDS EVEN 0 + Signal
9 RXE1- LVDS EVEN 1 - Signal
10 RXE1+ LVDS EVEN 1 + Signal
11 RXE2- LVDS EVEN 2 - Signal
12 RXE2+ LVDS EVEN 2 + Signal
13,14 GND Ground
15 RXEC- LVDS EVEN Clock - Signal
16 RXEC+ LVDS EVEN Clock + Signal
17 RXE3- LVDS EVEN 3 - Signal
18 RXE3+ LVDS EVEN 3 + Signal
19 RXO0- LVDS ODD 0 - Signal
20 RXO0+ LVDS ODD 0 + Signal
21 RXO1- LVDS ODD 1 - Signal
22 RXO1+ LVDS ODD 1 + Signal
23 RXO2- LVDS ODD 2 - Signal
24 RXO2+ LVDS ODD 2 + Signal
25,26 GND Ground
27 RXOC- LVDS ODD Clock - Signal
28 RXOC+ LVDS ODD Clock + Signal
29 RXO3- LVDS ODD 3 - Signal
30 RXO3+ LVDS ODD 3+ Signal
