6-2.Test program(test without water)
Push and hold the "CYCLE" and "start/pause" buttons, then
power switch to enter Test A program. Push the "CYCLE
and Test C programs.
Remarks:the indicators in the list are (in turn): quick, wash, rinse, spin.
indicator off indicator on indicator flash
Display before
running
Display during
running
Test A
The buzzer rings intermittently six
times (0.4s connected, 0.8s shutoff).
The program indicator flashes six
times. The power is switched off
automatically after finishing.
Test B
It will perform 2 minutes washing
eve n without wa ter (d uring running ,
you can change the current
selection)Remarks: the water level
switch is invalid. The power is
switched off automatically after
finishing.
Test C
2 minutes spinningWhen it detects
abnormal conditions such as
imbalance spinning, or the top lid is
open, it will alarm. Open the top lid
then close it to resume normal
operation. The power is switched off
automatically after finishing.
Selection indicator
Test name Test content
When in alarm
push down the
" to select Test B
Service Manual
Model No: HLP21N
Issue
Rev.
-18-

Haier HLP21N Specifications

General

Water consumption per cycle	- L
Energy consumption washing per cycle	- kWh
Dimensions (WxDxH)	447 x 438 x 760 mm
Power requirements	120V, 60Hz
Door hinge	Up
Drum volume	28 L
Loading type	Top-load
Drum material	Stainless steel
Product color	White
Built-in display	No
Appliance placement	Freestanding
Drum capacity	- kg
Spin-drying class	-
Maximum spin speed	700 RPM
Number of washing programs	3
Package weight	51800 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	438 mm
Width	447 mm
Height	760 mm
Weight	43000 g
