HSU-09(12)HA/HVA/RHA103/R2(DB) Capacity
45
Domestic air conditioner
outdoor temp.
(humidity 46%)
DB/WB 16℃
19
℃
22℃
15
℃
2020 2220 2300
25
℃
2040 2170 2230
30
℃
2410 2580 2650
35
℃
2715 2840 2920
40
℃
3020 3100 3190
45
℃
3370 3540 3580
HSU-12HA103/R2(DB) performance curves
COOLING DISCHARGE PRESSURE
.talbe
in
door temp.
COOLING DISCHARGE PRESSURE
1500
2000
2500
3000
3500
4000
15℃ 25℃ 30℃ 35℃ 40℃ 45℃
Outdoor Temp
D
ISCHARGE PRESSURE
16℃
19℃
22℃
