HSU-09(12)HA/HVA/RHA103/R2(DB) Capacity
46
Domestic air conditioner
outdoor temp.
(humidity 46%)
DB/WB 16℃
19
℃
22℃
15
℃
2008 2208 2288
25
℃
2028 2158 2218
30
℃
2398 2568 2638
35
℃
2703 2828 2908
40
℃
3008 3088 3178
45
℃
3358 3528 3568
HSU-12HVA103/R2(DB) performance curves
COOLING DISCHARGE PRESSURE
.talbe
in
door temp.
COOLING DISCHARGE PRESSURE
1500
2000
2500
3000
3500
4000
15℃ 25℃ 30℃ 35℃ 40℃ 45℃
Outdoor Temp
DISCHARGE PRESSURE
16℃
19℃
22℃
