Domestic Air Conditioner
36
Discharging Sensor
R176 =50K 3%
B77/176
=4450K 3%
Functions and Control
F
F
221 0.7641 0.6845 0.6127 24.08 39.15
223 0.7441 0.6661 0.5957 23.97 39.24
225 0.7247 0.6482 0.5792 23.88 39.33
226 0.7059 0.6308 0.5632 23.77 39.42
228 0.6877 0.6140 0.5478 23.67 39.49
230 0.6700 0.5977 0.5328 23.56 39.58
232 0.6528 0.5820 0.5183 23.47 39.67
234 0.6361 0.5667 0.5043 23.36 39.76
235 0.6200 0.5518 0.4907 23.25 39.85
237 0.6043 0.5374 0.4775 23.14 39.94
239 0.5891 0.5235 0.4648 23.04 40.01
241 0.5743 0.5100 0.4524 22.93 40.10
243 0.5600 0.4968 0.4404 22.82 40.19
244 0.5460 0.4841 0.4288 22.71 40.28
246 0.5325 0.4717 0.4175 22.60 40.37
248 0.5194 0.4597 0.4066 22.50 40.46
Temp.(℉)
Max.(KΩ) Normal(KΩ) Min.(KΩ)
-22 14646.0505 12061.7328 9924.4999 26.67 36.41
Torlance(℉
)
-20 13654.1707 11267.8730 9290.2526 26.69 36.39
-18 12735.8378 10531.3695 8700.6388 26.73 36.37
-17 11885.1336 9847.7240 8152.2338 26.74 36.36
-15 11096.6531 9212.8101 7641.8972 26.76 36.34
-13 10365.4565 8622.8101 7166.7474 26.78 36.32
-11 9687.0270 8074.3787 6724.1389 26.82 36.30
-9 9057.2314 7564.2244 6311.6413 26.83 36.28
-8 8472.2852 7089.4741 5927.0206 26.85 36.27
-6 7928.7217 6647.4547 5568.2222 26.89 36.25
-4 7423.3626 6235.7109 5233.3554 26.91 36.23
-2 6953.2930 5851.9864 4920.6791 26.92 36.21
0 6515.8375 5494.2064 4628.5894 26.96 36.19
3 5729.1413 4848.9963 4100.3708 27.01 36.16
5 5375.5683 4558.1906 3861.6201 27.03 36.14
7 5045.9114 4286.5535 3638.1938 27.05 36.12
9 4738.4141 4032.7098 3429.0191 27.09 36.10
10 4451.4586 3573.4260 3233.1039 27.10 36.09
12 4183.5548 3573.4260 3049.5312 27.14 36.07
14 3933.3289 3365.7336 2877.4527 27.16 36.05
16 3699.5139 3171.3148 2716.0828 27.19 36.03
18 3480.9407 2989.2460 2564.6945 27.21 36.01
19 3276.5302 2818.6731 2422.6139 27.25 36.00
