Contains fluorinated greenhouse gases
covered by the Kyoto Protocol
Important information regarding the refrigerant used
Emergency operation and test operation
This product contains greenhouse gases covered by the Kyoto
Protocol. Do not vent into the atmosphere.
Refrigerant type: R410A
GWP* value: 1975
GWP = global warming potential
Please
in with indelible ink,
1 the factory refrigerant charge of the product
2 the additional refrigerant amount charged in the and
1+2 the total refrigerant charge on the refrigerant charge label supplied
with the product.
The
out label must be adhered in the proximity of the product charging port
(e.g. onto the inside of the stop value cover).
A contains
greenhouse gases covered by the Kyoto Protocol
B factory refrigerant charge of the product: see unit name plate
C additional refrigerant amount charged in the
D total refrigerant charge
E outdoor unit
F refrigerant cylinder and manifold for charging
Room
temperature
Designated
temperature
Timer
mode
Fan
speed
Operation
mode
Above 23
o
C
Below 23
o
C 23
o
C
26
o
C
No
AUTO
AUTO
COOL
HEAT
No
Pi
emergency
operation switch
test operation
switch
Pi
Pi
Emergency Operation:
Use
run automatically for a short time.
this only when the remote controller is defective or lost. air conditioner can
When the emergency operation switch is pressed, the “Pi“ sound is heard once,
which means emergency operation has started.
When power switch is turned on for the time and emergency operation
starts, the unit will run automatically in the following modes:
Test operation:
The test operation switch is the same as the emergency switch.
Use this switch in the test operation when
the room temperature is below 16°C.
Do not use it during normal operation.
Continue to press the test operation switch
for more than 5 seconds . After you hear the
“Pi” sound twice, release your
from
the switch: the cooling operation starts with
the air
speed “Hi”.
Under this operation mode, the fan motor of indoor unit will run in high speed.
It is impossible to change the settings of temperature fan speed, or to operate in
timer or dry mode.
