Haier HTR13 - Ics Functional Description

12
U DL 0 ~ 3 3 № U signal delay adjust
V DL 0 ~ 3 0 № V signal delay adjust
LCNR 0 ~ 63 32 № Down pillow shape distortion
P11：
Items Preset Remark Description
C TRAP 0 ~ 3 2 № Colour trap wave adjust
H VCO 0 ~ 7 3 № Row frequency adjust
SIF BFP 0 ~ 3 0 № SIFstrap pass width choice
SIF45 G DN 0 ~ 1 0 №
4.5Mhz sound plus attenuation switch； 0 = normal； 1 =
attenuation。
STRAP OFF 0 ~ 1 0 № Sound trap wave switch
AFC1 UP 1 0 ~ 1 1 № Level AFC1 plus adjust
AFC1 UP 2 0 ~ 1 1 № Level AFC1 plus adjus
AFC2 DOWN 0 ~ 1 0 № Level AFC2 plus adjus
AFC2 UP 0 ~ 1 1 № Level AFC2 plus adjus
.
5. ICs functional description
1. IC201 R2J10165GC
SYMBOL PIN DESCRIPTION
SP00/14bPWM 1 SP00/14bPWM
SP01/PWM 2 SP01/PWM
SP02/PWM 3 SP02/PWM
SP03/PWM 4 SP03/PWM
TEST0 5 TEST0
P04/AD2 6 P04/AD2
P05/AD1 7 P05/AD1
P06/TIM31 8 P06/TIM31
AFT(AD0) 9
SIF auto phase control
DEF VCC(8.0V) 10 8V POWER
V RAMP(+) 11 V RAMP(+)
VRAMP CAP 12 VRAMP CAP
AFC 1 FIL 13
SIF auto phase control filter
DEF VCC(5.0V) 14 5V POWER
H OUT 15 Horizontal SIGNAL OUT
FBP IN 16 FBP IN
DEF GND 17 GND
VRAMP AGC 18 VRAMP AGC
Cb IN YcbCr 19 Cb IN YcbCr
Cr IN YcbCr 20 Cr IN YcbCr
C-APC 21 C-APC
XTAL 22 XTAL
CHROMA GND 23 CHROMA GND
Y SW OUT 24 Y SW OUT
TEST/EW OUT 25 TEST/EW OUT
MCU 5.7 VDD OUT 26 MCU 5.7 VDD OUT
PAL ID FIL 27 PAL ID FIL
8.7V REG OUT 28 8.7V POWER OUT
EXT AU(L)IN/EXT AU2
IN
29 EXT AU(L)IN/EXT AU2 IN
EXT2 IN/C IN YC 30 EXT2 IN/C IN YC
CHROMA VCC(5.0) 31 CHROMA VCC(5.0)
EXT 1 IN/YIN YC/YIN Y
CbCr
32 EXT 1 IN/YIN YC/YIN Y CbCr
5.7V REG OUT 33 5.7V POWER OUT
VIF VIDEO OUT 34 VIF VIDEO OUT
VIF GND 35 GND
