3
Do…
Make sure that the transport bolt is removed.
Use a separate earthed socket for the power supply.
Make sure that the plug is accessible.
Hold the plug and not the electric cable when unplugging the
power supply.
Make sure that the fuses in the power circuit are rated for 15A.
and rubber components from aging.
Make sure that the power card is not caught under or in the appliance and avoid damage to
the power cable.
firm there will be leakage, turn othe water supply and refix it. Do not use the washing
.
Do not…
Touch or use the appliance when barefoot or with wet or damp hands or feet.
Use flammable detergent or dry cleaning agent.
Use anyammable sprays in close vicinity to the appliance.
Remove or insert the plug in presence of flammable gas.
Allow children or infirm persons to play with the appliance or packing materials.
Install the appliance outdoors in a damp place, or in an area which may be prone to water
leaks such as under or near a sink unit. In the event of a water leak allow the machine to dry
naturally.
Place the washing machine directly on a carpet, or close to a wall or furniture.
During daily use of the appliance
Do…
Pull up zips and fix loose threads to prevent the items from being entangled. If necessary, put
small items into a small bag or pillow.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory
concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with
the appliance. Cleaning and user maintenance shall not be made by children without supervision.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Haier HW70-14636 and is the answer not in the manual?

Haier HW70-14636 Specifications

General IconGeneral
TimerYes
Drum capacity7 kg
Cycle time (max)200 min
Residual moisture53 %
Spin-drying classB
Maximum spin speed1400 RPM
Minimum spin speed400 RPM
Noise level (spin)67 dB
Noise level (wash)58 dB
Delayed start timer-
Load balancing systemNo
Number of washing programs16
Cycle time (quick washing program)15 min
Door hingeLeft
Control typeButtons, Rotary
Loading typeFront-load
Product colorWhite
Illumination colorAmber
Appliance placementFreestanding
Current10 A
Connected load2000 W
AC input voltage220 - 240 V
AC input frequency50 Hz
Power consumption (off)0.48 W
Energy consumption washing per cycle0.747 kWh
Washing classA
Annual water consumption washing10908 L
Annual energy consumption washing170 kWh
Package weight67000 g
Weight and Dimensions IconWeight and Dimensions
Depth510 mm
Width595 mm
Height850 mm
Weight64000 g
