Haier HW70-14636 User Manual

8
Control Panel
1.
2.
3. Program Dial
4. Wash Temp
5. Spin Speed
6.
7. Extra Rinse
8.
9.
10. LED Display
Delay
Oper onal Func ons
Nº Func on Explica on
1 Detergent
drawer
2
Program Dial
Wash Temp
Spin Speed
3
4
5
6
ons
Open the drawer, three compartments can be seen:
Compartment 1: Prewash detergent (for prewash mode).
Compartment 2: Detergent for programs 1 to 15.
By turning the knob clockwise/counterclockwise, the required program can
corresponding light will illuminate.
indicator. Select a temperature according to the type of laundry.Note: If there
is no indicator light displayed, this means cold w ash.
will be displayed on the indicator.Note: If there is no indicator light displayed,
this means no spinning.
Di
erent water temperatures and spinning speeds can be set for
special requirement.
1
2
for the various washing temperatures, please refer to the
manual of detergent.
6
very dirty,
.
1
4
01
2
3
5
6
7 98

Haier HW70-14636 Specifications

General

Timer	Yes
Drum capacity	7 kg
Cycle time (max)	200 min
Residual moisture	53 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	67 dB
Noise level (wash)	58 dB
Delayed start timer	-
Load balancing system	No
Number of washing programs	16
Cycle time (quick washing program)	15 min
Door hinge	Left
Control type	Buttons, Rotary
Loading type	Front-load
Product color	White
Illumination color	Amber
Appliance placement	Freestanding
Current	10 A
Connected load	2000 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.48 W
Energy consumption washing per cycle	0.747 kWh
Washing class	A
Annual water consumption washing	10908 L
Annual energy consumption washing	170 kWh
Package weight	67000 g

Weight and Dimensions

Depth	510 mm
Width	595 mm
Height	850 mm
Weight	64000 g
