7
Inlet Hose
Connect the nut on the inlet hose to the
connector on the water valve.
Connect inlet hose to a water tap with cold,
fresh water.
Use the hose-set supplied with the appliance.
Old hose-sets should not be reused.
Drain Hose
Use the drain hose bracket to keep the end of the
drain hose retained and prevents the
of
water. Don't extend the length of the drain hose; if
an extended hose is required, please consult a
serviceman or plumber.
The height of the drainage outlet must be 80-100
cm. Fix the drain hose to the clip at the back of the
washing machine to prevent it from dropping o.
The drain hose should not be submerged in water and should be securely xed and leak-free.
If the drain hose is placed on the ground or if the pipe is at a height of less than 80cm, the
washing machine will con
nuously drain while being lled (self-siphoning).
Conne
ng to Power Supply
Before connec ng to the power supply, check:
The socket is adequate for the maximum power of the washing
machine (For safety, fuses in the power circuit should be rated
for no less than 10A).
The voltage should meet the requirement
The power outlet should be capable of accep ng the washing
machine plug.
Connect the machine to an earthed socket outlet.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Haier HW70-14636 and is the answer not in the manual?

Haier HW70-14636 Specifications

General IconGeneral
TimerYes
Drum capacity7 kg
Cycle time (max)200 min
Residual moisture53 %
Spin-drying classB
Maximum spin speed1400 RPM
Minimum spin speed400 RPM
Noise level (spin)67 dB
Noise level (wash)58 dB
Delayed start timer-
Load balancing systemNo
Number of washing programs16
Cycle time (quick washing program)15 min
Door hingeLeft
Control typeButtons, Rotary
Loading typeFront-load
Product colorWhite
Illumination colorAmber
Appliance placementFreestanding
Current10 A
Connected load2000 W
AC input voltage220 - 240 V
AC input frequency50 Hz
Power consumption (off)0.48 W
Energy consumption washing per cycle0.747 kWh
Washing classA
Annual water consumption washing10908 L
Annual energy consumption washing170 kWh
Package weight67000 g
Weight and Dimensions IconWeight and Dimensions
Depth510 mm
Width595 mm
Height850 mm
Weight64000 g
