Haier HW80-B1486 Service Manual

SERVICE MANUA L
HW80-B1486/HW80-B1286
6-2 Self check
Front Load W ashing Machine
1. How to start
Press the "Intense" and Pr ewas but ton, the nplug on the m achi ne," tESt"will be displayed by tur
Press
Start/Pause but ton , the model of the machine wi ll be displayed( suchas 1480).Pres
button again,the machine will start a self test program, then the following will be performed.
2. T est item
1) When the door switch is closed for three seconds, 88: 88 w ill be displayed.
O
ther wise"Err1"will be di splaye
2) when the main wash valve allows water to let in for 5 sec o nds, when the prewash valve allows water to let in for
5 seconds, when the intenerate valve allows water to let i n for 5 seconds, come into next water level, 77: 77 wil
be displayed, If the water can not reach the level in 2 minutes," Err5 " will be displayed. If the water exceeds the
overflow level, " Err8 " will also be displayed.
3) When the washing machine heats water for 10 seconds, 66:66
will be displayed
4) When the washing machine drains for 2 minutes, if no w ater left , 55: 55 will be displayed
Otherwise " Err2 " will be displayed.
5) When the inner drum runs for ten seconds with the spee d of 90 rpm at this time and for thirty seconds with the
speeds of 800rpm 44:44 will be displayed.
6) When the self check program is completed, "End" will be d i splayed.
6-3. Model selection
When the display board (on the control panel) is replaced t echnician need to select the correct model according with
the model name on the washing machine.
1 Press the Rinse button and then plug on the machinet the same time,Then 14 80" will be displayed ont he screen
2 Press the
Spee d button to choose correct speed
1680-1480--1470-1460-1280-1270-1260--1080-1070-1060 will be displayed by turn.
Then press the Temp. buttont save
For this model
HW80- B1486/HW80-B1286
please choos
3 If you want to change the model again after storage, you c an cut o f f the NTC and do the cycle adjustment.
1
1
6
6
s
l
Start/Pause
1480
1280

Haier HW80-B1486 Specifications

General

Current	10 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (typical)	2000 W
Water consumption per cycle	- L
Energy consumption washing per cycle	- kWh
Washing class	A
Annual water consumption washing	11440 L
Annual energy consumption washing	186 kWh
Display type	LCD
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Drum capacity	8 kg
Delay start (max)	24 h
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	74 dB
Noise level (wash)	53 dB
Number of washing programs	12
Package weight	78000 g

Weight and Dimensions

Depth	650 mm
Width	595 mm
Height	850 mm
Weight	74000 g
