Haier HW80-B1486 Service Manual

SE RVICE MANUL
HW80-B1486/HW80-B1286
Haier Front Load W ashing Machine
15
Error message: The required wa ter level is not reach ed wi thin 8 min.
Tr oubleshoo t ing:
N
Che ck i f inle t valv e i s jammed
Clean inle t valv e
N
Dr aw out the di spenser and check if
wat
er is en t erin g
Ob s er ve if th e
heigh t of drain pi pe
no
t reac h 80 cm. If
water
level senso r
and the hose is
leaking gas
N
T urn on power, and set pre -wash
mode, then star t. Check the impor t
vol t age of electromagnetic valve by
multimeter is it bet w ee n AC
220-240V?
Electromagnetic valve mus t be broken, pleas e
replace it.
N
Check if t ap is closed or water
pressure is too low (u s ua l
be tw een 0.03 -1 MP a)
Open t he t ap or w ait for no rmal w at er
pressure to us e
The wire conne c ted PCB an d inlet valve is no t
pr
ope rly . P lea se rec onne ct it o r r e pla ce i t.
Y
Y
Y
Y
Y
Check if wa ter is leaking from wa she r
bott om . I nle t pipe . drain pipe or
other pipe conn e ction
Y
Replace PCB
Check if export vol t age from PCB to
elec t romagne t ic valve (between X3-1
and X3-7), is it between AC 220-2 4 0V?
N
N
Connect it well.
X3-7
X3-1

Haier HW80-B1486 Specifications

General

Current	10 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (typical)	2000 W
Water consumption per cycle	- L
Energy consumption washing per cycle	- kWh
Washing class	A
Annual water consumption washing	11440 L
Annual energy consumption washing	186 kWh
Display type	LCD
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Drum capacity	8 kg
Delay start (max)	24 h
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	74 dB
Noise level (wash)	53 dB
Number of washing programs	12
Package weight	78000 g

Weight and Dimensions

Depth	650 mm
Width	595 mm
Height	850 mm
Weight	74000 g
