8. Performance Curves
(1) Calculation method of cooling capacity
----cooling capacity to be known = cooling capacity*(A*B*C*D*E) W
E. Capacity compensation value of pipe
length, pipe diameter and height drop
C. Capacity modication value under
airow ariation rate of indoor unit group
(only for duct unit)
A. Capacity compensation value of indoor
air wet-bulb temperature condition
B. Capacity compensation value of outdoor
air dry-bulb temperature condition
D. Capacity compensation suitable for
total capability of indoor unit group
1.2
1.1
1.0
0.9
0.8
15 20 24
Indoor air wet-bulb temperature (°C )
Capacity modication value
1.2
1.1
1.0
0.9
Outdoor air dry-bulb temperature (°C )
Capacity modication value
-5 200 255 3010 3515 40 43
1.1
1.0
0.9
80 90 100 110 120
Airow variation rate (%)
Capacity modication value
120
100
100 120 130
80
60
40
20
20
40 60 80
0
Total capacity of indoor unit group (%)
Standard capacity
Capacity modication value
AU032FSEUA
