Front Panel Controls
Control Panel Function
6
7
TV/AV MENU VOL- VOL+ CH- CH+ POWER
2 3 4 5
1. Power supply switch
2.TV/AV Select the input signals: SCART/DVD/PC/AV/SV/TV
3. MENU Press to select the main menu
4. VOL- Volume down / Left orientation to adjust the item in the OSD
VOL+ Volume up / Right orientation to adjust the item/Press to enter
5. CH- TV channel down / to select the item in the menu
CH+ TV channel up / to select the item in the menu
6. Power indicator
Illuminates red in standby mode, illuminates green when the display is
turned on
7.Remote Sensor Receiving remote control sends the infrared remote
signal.
1
