Haier L1920A-C User Manual

AV Input
Connect audio/video
output from an external
device to these jacks
VGA Input
Connect to the VGA
15PIN analog output
connector of the PC
display card for PC
display purpose
S-Video Input
Connect S-Video out
from an S-Video device
to the jacks.
Antenna Input
Connect cable or
antenna signals to
the TV, either direc-
tly or through your
cable box.
Connection Options
Earphone port
PC Audio Input
Connect the PC output
connector from a PC to
the audio input port
SCART
Connect to the DVD/
VCR/broadcasting
receiver or other
equipment
The figure is just for reference, please see the real.
And the AC power supply switch is on the back of the set)
ANT IN
AUDIO IN
R
L
VIDEO IN S-VIDEO
TV SCART
VGA IN
PC AUDIO IN
ANT IN
AUDIO
R
L
VIDEO IN S-VIDEO
SCART VGA IN
PC AUDIO IN
DVD
STOP PLAY/PAUSE OPEN/CLOSE
PREW NEXT
DVD insert

Haier L1920A-C Specifications

General

Brand	Haier
Model	L1920A-C
Category	TV Receiver
Language	English
