- 10 -
Service Manual
Model No.:
Pin number Signal name Description
1 LED_R LAMP RED
2 LED_G LAMP GREEN
3
4 IR REMOTE CONTROL
5 GND GND
6 5V POWER FOR REMOTE
Pin number Signal name Description
1 KEY1
2 KEY0
3 GND
remote connector (CN201)
Keypad and connector (CN202)
Speaker connector CN701
Pin number Signal name Description
1 RSPK+ RSPK+
2 RSPK- RSPK-
3 LSPK- LSPK-
4 LSPK+ LSPK+
