- 08 -
Service Manual
Model No.:
3. Location of Controls and Components
3-1 Board Location
No. Part Number Description
3-2 Main Board & AV Board
A Board
B Board
A Board DC1KK0M0101M Main Board
B Board 514C2411M14 Power Board
