Haier L22C360 - Power Board; 3-3-1 Function Description

3-3. Power Board
3-3-1 Function Description:
Supply power for Main board, Panel.
Service Manual
Model No.:
- 11 -
CON5
3
4
5
6
7
8
9
10
11
12
1
2
POWER ON/OFF
+5VSTB
+5V
GND
GND
+12V
+12V
BL ON
GND
+5V
GND
DIM
