Side and rear terminals
5
4
1
7
6
3
2
9
8 107
VIDEOLR
AV IN 2
USB
HDMI 3
Explanations on the rear terminals and their functions:
1
COMPONENT: Color aberration component (YCbCr, YPbPr) Video/
Audio Input Terminal
2
AUDIO IN: VGA audio input terminal
3
PC IN: VGA video input terminal
4
AV IN 1: AV IN 1 audio/video input terminal
5
AV OUT: AV audio/video output terminal
TV ANTENNA: Antenna input terminal
HDMI1/HDMI2/HDMI3 input terminal
AV IN 2: AV IN 2 audio/video input terminal
Earphone output socket
USB
Panel control and rear terminal control
