Indoor unit side (2 pipes)
Gas Pipe (Ø15.88)
Liquid Pipe (Ø9.52)
Outdoor unit side (3 pipes)
112B
HP gas Pipe (Ø12.7)
Suction gas Pipe (Ø15.88)
Liquid Pipe (Ø9.52)
Outdoor unit side (3 pipes)
180B
HP gas Pipe (Ø15.88)
Suction gas Pipe (Ø15.88)
Liquid Pipe (Ø9.52)
Indoor unit side (2 pipes)
Gas Pipe (Ø15.88)
Liquid Pipe (Ø9.52)
Outdoor unit side (3 pipes)
HP gas Pipe (Ø19.05)
Suction gas Pipe (Ø22.22)
Liquid Pipe (Ø9.52)
Indoor unit side (2 pipes)
Gas Pipe (Ø22.22)
Liquid Pipe (Ø9.52)
