SW03 is used for valve box address setting
SW03_1
Manner of set
address
OFF Set the address with automatism
（
default
）
ON Set the address with dip switch
SW03_2 Pre-set
OFF Pre-set
（
default
）
ON Pre-set
SW03_3
~
SW03_8
Set the
communication
address with dip
switch
[3] [4] [5] [6] [7] [8] Communication address
OFF OFF OFF OFF OFF OFF 0#
（
default
）
OFF OFF OFF OFF OFF ON 1#
OFF OFF OFF OFF ON OFF 2#
OFF OFF OFF OFF ON ON 3#
OFF OFF OFF ON OFF OFF 4#
OFF OFF OFF ON OFF ON 5#
OFF OFF OFF ON ON OFF 6#
OFF OFF OFF ON ON ON 7#
OFF OFF ON OFF OFF OFF 8#
OFF OFF ON OFF OFF ON 9#
OFF OFF ON OFF ON OFF 10#
OFF OFF ON OFF ON ON 11#
OFF OFF ON ON OFF OFF 12#
OFF OFF ON ON OFF ON 13#
OFF OFF ON ON ON OFF 14#
OFF OFF ON ON ON ON 15#
OFF ON OFF OFF OFF OFF 16#
OFF ON OFF OFF OFF ON 17#
OFF ON OFF OFF ON OFF 18#
OFF ON OFF OFF ON ON 19#
OFF ON OFF ON OFF OFF 20#
OFF ON OFF ON OFF ON 21#
OFF ON OFF ON ON OFF 22#
OFF ON OFF ON ON ON 23#
OFF ON ON OFF OFF OFF 24#
OFF ON ON OFF OFF ON 25#
OFF ON ON OFF ON OFF 26#
OFF ON ON OFF ON ON 27#
OFF ON ON ON OFF OFF 28#
OFF ON ON ON OFF ON 29#
OFF ON ON ON ON OFF 30#
OFF ON ON ON ON ON 31#
ON OFF OFF OFF OFF OFF 32#
ON OFF OFF OFF OFF ON 33#
ON OFF OFF OFF ON OFF 34#
ON OFF OFF OFF ON ON 35#
