49
Model
AV88IMVURA
Outdoor fan
Brand Tian Da+Tian Da+Tian Da+Tian Da
Model /
Material ABS+20%GF
Type Axial
Diameter mm Φ642+Φ642+Φ642+Φ642
Height mm 198+198+198+198
Outdoor
coil
Number of rows 3+3+3+3
Tube pitch(a)x row pitch(b) mm 21×18.186
Fin spacing mm 1.60
Fin type (code) Hydrophilic aluminum
Fin Coating Type Optional Clear lacquer
Salt Spray Test Duration Hour 168
Tube outside dia.and type INNERGROOVE TUBE
mm Ф7
Coil length x height mm
(2843*1260+2757*1260+2669*1260)+(2843*1260+2757*1260+2
669*1260)+(2843*1260+2757*1260+2669*1260)+(2843*1260+2
757*1260+2669*1260)
Number of circuits 30+30+30+30
Cabinet
coating
Coating type Powder Coating
Salt Spray Test Duration Hour 72
Sheet Metal Material Hot zinc plate
Sheet Metal Thickness mm 1
Control panel enclosure IP class standard IP24
Outdoor air ow (cooling / heating) m3/h 76000
External static pressure Pa 110
Outdoor sound level(sound pressure level )(H) dB(A) 70
Outdoor sound level(sound power level ) (H) dB(A) 91
Outdoor
unit
Dimension(W*D*H) mm 1410/750/1690+1410/750/16901410/750/1690+1410/750/1690
Packing (W*D*H) mm 1515/850/1838+1515/850/1838+1515/850/1838+1515/850/1838
Net weight kg 1500
Gross weight kg 17616
Refrigerant
Type R410A
Charged volume kg 10
Throttle type EXV
Design pressure MPa 4.15
Refrigerant
piping
Liquid pipe mm 25.4
Gas pipe mm 50.8
High gas pipe mm 44.5
Oil pipe mm /
Total pipe length m 1000
Max. pipe length(Equivalent/ Actual) m 260/220
Max. Diff. indoor/outdoor unit*1 m 110/90
Standard Diff. indoor/outdoor unit m 50/40
Max. / standard Diff. indoor/indoor unit*1 m 30/18
Connectable indoor unit ratio % 50~130
Maximum indoor units Piece 64
Connection
wiring
Max. fuse current A 252
Min. wiring current A 218.00
Power wiring mm2 95.00
Signal wiring mm2 2
X 0.75
Operation Range °C Cooling: -5~50 Heating: -23~21
Norminal condition: indoor temperature (cooling): 27°C DB/19°C WB, indoor temperature (heating): 20°C DB/14.5°C WB.
Outdoor temperature(cooling): 35°C DB/24°C WB, outdoor temperature(heating): 7°C DB/6°C WB The data is measured with 7.5m equivalent
pipe and 0 m height difference.
The noise level will be measured in the third octave band limited values in the semi-anechoic chamber, using a Real Time Analyser calibrated
sound intensity meter. It is a sound pressure noise level.
*1 If the total pipe length is from 500 to 1000m or the height difference between the outdoor and indoor units is from 50 to 110m or the height
difference between the indoor units is from 18 to 30m, you Must contact your local distributor/dealer for individual design and production.
