Hakko Electronics FM-2023 - Packing List; Specifications

10
9. PARTS LIST
1
5
3
2
 Tips
2
1
4

Mini parallel remover
Item No. Part No.
B2300
B2847
B2848
A1519
B2849
Part Name
Heat resistant pad
Tip ID number key
Holder clip
Cleaning sponge
Component bed
Handpiece only
Specifications
With screw
6
FM2023-02
Part No.

T9-I

T9-L1


T9-L2
Part Name

Tip/CHIP I

Tip/CHIP 1L

Tip/CHIP 2L
Size A

-----
1 mm (0.04 in.)


2 mm (0.08 in.)
Shape
A
-----
w/o tip
2
1
3
4
5
6
1
1. PACKING LIST
Mini parallel remover handpiece ........... 1
Tips (T9-I) 2pcs/set ................................
1
Heat resistant pad ..................................
1
Cleaning sponge ....................................
1
Heat resistant pad
Tip ID number key
Holder clip
Mini parallel remover handpiece
Tip (shape-I)
Component bed
Cleaning sponge

Applicable Models
In order to function, the FM-2023 must be connected to the FM-202 soldering station.
2. SPECIFICATIONS
 FM-2023 Mini parallel remover
Power Consumption
Temperature Range
Tip to Ground Resistance
Tip to Ground Potential
Cord Assembly
Total Length (w/o cord)
Weight (w/o cord)
Standard tip
140W (24 V)
200 – 400°C (400 – 750°F)
< 2

< 2mV
1.2m (4 ft.)
75mm (w/o tip)
32g (Handpiece only), 5g (I tip only)
T9-I (Shape-I)

 Specifications and design are subject to change without notice.
Tip ID number key .................................. 1
Holder clip (w/screw) ..............................
1
Component bed ......................................
1
