Trailer Axle
Figures 5-8 show typical brackets for automatic brake adjuster applications
on trailer axle brake assemblies. Refer to pages 4 and 5 for detailed
installation procedures.
3
Figure 5
For 16-1/2” Brake Assemblies
Note: Refer to fundamental parts identification and location on page 10.
Typical Applications
Figure 7
Integral cam support anchor bracket
for 12 1/4” and 15 1/2” brakes
Figure 8
Bolt-on cam support anchor bracket
for 12 1/4” and 16 1/2” brakes
Figure 6
For 12-1/4” Brake Assemblies
