HP SERIES
PORTABLE PUMPS
USER OPERATION AND MAINTENANCE
58
PL-4: HP100 PUMP END AND GEARBOX
1 018-8250-00-0 STUD-HP SERIES VALVE STOP M8 1.0 EA
2 538-1450-01-0 HP100 DISCHARGE VALVE ASSEMBLY 1.0 EA
3 218-0408-19-0 SCREW M4-.7X16 SOC.HD. LOCK 1.0 EA
4 012-0170-02-0 HANDWHEEL-HP SERIES DISCHARGE 1.0 EA
5 210-0805-11-0 NUT M8-1.25 STNLS STL LOCKING 9.0 EA
6 097-1750-03-0 HP100 VALVE WASHER 1.0 EA
7 097-1760-01-0 HP100 VALVE SEAL WASHER 1.0 EA
8 097-1750-02-0 HP100 VALVE BACKUP WASHER 1.0 EA
ITEM PART NUMBER DESCRIPTION QTY UNIT
4
3
14
13
12
1
10
9
8
7
6
18
19
17
5
15
16
23
20
22
24
25
26
28
27
30
29
31
48
45
46
47
44
43
42
41
39
40
38
36
33
32
35
34
18
21
11
NOTE: Items 1 through 16 are not
provided with "X" Series pump.
37
To Next Page
