46
These sketches can just be seen as a rough guidance, since the distance of the slings, depending on the
design of each individual crane, affects where to best put the slings.
310, 342, 372, 37, 412
HR 40, 43, 48, 55, 64
S
p
ace for life raft
Space for life raft
Reinforced area for life raft cradle,
400 mm from centre of
reinforcement to centre of
reinforcement
