Haloview CA112 - Page 4

Figure3: Unscrew the LED Marker Light
Figure4: Remove the marker light and pull out the cables
Fig.3 Fig.4
Fig.5 Fig.6
Figure5: Cutting the cables by a plier
Figure6：Stripping the cables to expose the conductive core
Fig.7 Fig.8
Fig.9 Fig.10
Figure7/Figure8/Figure9: Ensure correct polarity when wiring the cables.
Red + Black -
-2-
