Figure10/Figure11: Wire connections and terminals must be sealed
and waterproof.
Fig.17 Fig.18
Figure12/Figure13/Figure14/Figure15:
Clamp the terminal tightly to make sure they are sealed and waterproof.
Fig.11 Fig.12
Fig.13 Fig.14
Fig.15 Fig.16
Figure16：Put the wires and terminals into hole and align the camera
to screw holes.
-3-
