Refer to Figure 54
Key G C Part No. Description No off Makers Pt No.
1 H29-740 Electrode - Ignition c/w Gasket 1 988526
2 H38-213 Detection Electrode c/w Gasket 1 988540
3 H29-236 Spark Generator c/w Lead 1 500665
4a H38-214 Gas Control Valve Assy - NG (Ace HE24 & 30) 1 988541
4b Gas Control Valve Assembly - NG (Ace HE35) 1 988563
5 H38-215 Fan Assembly 1 601016
6A H29-171 Burner (Ace HE 24) 1 700600
6B H29-172 Burner (Ace HE 30) 1 700601
7 H38-216 Insulation - Burner Door 1 451106
8A H38-217 Heat Exchanger (Ace HE 24) 1 451101
8B H38-218 Heat Exchanger (Ace HE 30) 1 451100
9 H29-202 Pump Head 6m 1 500672
10 H29-203 Valve - Diverted - Motorised Head 1 500673
11 H29-201 Hydroblock Pump Assembly 1 500650
12 H29-237 Expansion Vessel 1 451020
13 H29-199 Valve 3Bar - Pressure Relief 1 300734
14 H29-213 Sensor - Water Temperature 2 500661
15 H38-219 Thermistor - Flue 1 500662
16 H29-190 Heat Exchanger - 16 Plate 1 451015
17 H29-192 CH Filter - Plate Heat Exchange 1 500498
18 H38-220 Thermistor - Outlet - DHW 1 500663
19 E23-541 Pressure Gauge 4bar - Altecnic IC96467238 1 450961
20 H29-204 Air Vent - Auto 1 500674
21a H38-221 Control PCB c/w Box Assembly (Ace HE 24) 1 988542
21b H38-222 Control PCB c/w Box Assembly (Ace HE 30) 1 988543
21c Control PCB c/w Box Assembly (Ace HE 35) 1 988562
22 H38-223 User Control Fascia Assermbly 1 988544
23 E23-671 Time Clock - Grasslin FM1STUH 1 600520
24 H38-224 Air Vent Pipe c/w Seal 1 988545
25 H38-225 Switch - Flow - DHW 1 300695
26a H08-702 DHW Flow Regulator (Ace HE 24) 1 300717
26b E23-692 DHW Flow Regulator (Ace HE 30) 1 300715
26c DHW Flow Regulator (Ace HE 35) 1 300718
27 H29-260 Filter - Conical - Mains Inlet 1 500497
28 H29-179 Valve - Manual Bleed 1 300730
29 H38-226 Heat Exchanger c/w Seals & Clip Kit 1 988546
30 H29-208 Kit - Hydroblock - O-Ring and Clip 1 988490
SHORT PARTS LIST
10
41
751094 ACE HE INST MANUAL:751094 ACE HE 28/9/10 09:46 Page 43
