2.4
OVERALL DIMENSIONS AND MINIMUM CLEARANCES
The Ace HE24, HE30 and HE35 can be installed to a number of
different concentric flue systems. The different flue applications as
shown in Figure 2 are available as kits usually comprising the
2.5
CONCENTRIC AIR / FLUE DUCT SPECIFICATIONS
8
FLUE OPTIONS
connecting parts to the appliance and end terminal. Flue
extension ducts and extension elbows are available as
accessories.
1
The following flue systems are available for the ACE HE range
2
327mm
136mm
Ø100mm
97mm
200mm
5mm
5mm
200mm
SEE NOTE
NOTE:
5mm for normal
operation.
450mm for
installation and
servicing
907mm
446mm
758mm
173mm
4
